SALE 13″ Medical Tablet PC | MD-130

arrow
arrow
Certifications
products
md_130

Highlights

The MD-130 13.3″ Medical Tablet PC combines high performance, versatility, and reliability to meet the demands of modern healthcare environments. With a Full HD IPS LCD screen (1920 x 1080), powered by a fanless Intel® Tiger Lake i5-1135G7 processor and Intel Iris Xe Graphics, this device ensures crystal-clear visuals and smooth operation for medical imaging and diagnostics. Available with Windows 11 Pro or Windows 11 IoT, the MD-130 offers tailored flexibility for a range of healthcare applications. The integrated 180° kickstand doubles as a convenient handle, enhancing mobility, while customizable I/O ports connect seamlessly to essential medical imaging devices, such as portable X-ray, ultrasound, and endoscope systems. Designed for durability, it includes IP54-rated protection, a 6-hour high-capacity battery, and a 10-point capacitive touchscreen with glove and wet touch support, making it ideal for dynamic healthcare settings.

Features

  • 13.3″ IPS LCD Screen (1920 x 1080 Resolution)
  • Intel® Tiger Lake i5-1135G7 Processor with fanless design
  • Powerful Intel Graphic GPU
  • Windows 11 Pro or IoT
  • 66.3Wh High-Capacity Battery
  • IP54 Water & Dust Protection
  • Capacitive 10-Point Multi-Touch: Support Glove and Wet Touch Support
  • Versatile 180° Kickstand that can be served as a handle
  • Customizable Medical Imaging I/O port for X-ray, Ultra-sound, and Endoscope
see detail specification in WIKI see detail specification in WIKI for register see detail specification in WIKI FOR COSTOM
$2,399.00
delivery
in stock
DESCRIPTION
CONFIGURE & BUY
DESCRIPTION

Exceptional Performance and Multitasking Power for Healthcare Applications

The MD-130 Medical Tablet PC is purpose-built to handle the rigorous demands of healthcare applications, powered by the Intel Tiger Lake i5-1135G7 processor with a max turbo frequency of 4.2GHz and 8 MB of Intel® Smart Cache. Featuring a powerful Intel Iris Xe Graphics GPU, the MD-130 delivers smooth and responsive performance, optimized for demanding visual tasks such as medical imaging and diagnostics. With 16GB of LPDDR4 memory and a 256GB NVMe Gen 4 SSD, it provides the speed and storage needed for seamless multitasking in healthcare environments. Running on either Windows 11 Pro or Windows 11 IoT—both optional to suit specific healthcare needs—the MD-130 offers a secure and versatile platform tailored for electronic medical records (EMR) management, diagnostics, and telemedicine. Besides, its fanless design supports quiet operation, making it ideal for hospital and clinical settings, and an indispensable tool for healthcare professionals who need reliable, high-performance technology.

Customizable I/O Ports for Advanced Medical Imaging Integration

The MD-130 Medical Tablet provides customizable I/O ports designed for seamless integration with essential medical imaging equipment, optimizing clinical workflows and enhancing diagnostic precision. Built for compatibility with X-ray, ultrasound, and endoscopic systems, the MD-130 enables healthcare professionals to view high-quality images directly on a portable, reliable device. With versatile connectivity options—including USB 3.0 and USB-C with support for both display and power—the MD-130 adapts to various medical setups, ensuring effortless integration with critical imaging devices. This flexibility transforms the MD-130 into a multifunctional imaging hub, supporting real-time diagnostics and empowering healthcare professionals to deliver exceptional patient care.

Durability for Healthcare Environments

Built to withstand the demands of clinical settings, the MD-130 is IP54-rated for water and dust resistance. Its durable yet lightweight chassis—crafted from high-grade plastic, TPU, and aluminum alloy—weighs just 2.4 kg, while its versatile 180° kickstand functions as both a stand and a convenient handle, allowing medical staff to position, carry, and stabilize the device with ease.

Brilliant Display with Superior Touch Responsiveness

The MD-130 Medical Tablet is equipped with a 13.3-inch Full HD IPS LCD display, providing a 1920 x 1080 resolution and a brightness of 400 nits. This display ensures crisp visuals and clear readability in various lighting conditions, essential for accurate medical imaging and patient data management. Its capacitive 10-point multi-touch screen supports both glove and wet touch interactions, offering rapid and precise touch response—ideal for healthcare settings where hygiene and efficiency are paramount.

Reliable Connectivity for Enhanced Medical Workflow

Featuring Intel® AX210 Wi-Fi 6E for high-speed, reliable connectivity over both 2.4 GHz and 5 GHz bands, the MD-130 supports seamless communication and real-time data transfer within clinical workflows. Bluetooth® 5.2 enables secure connections to essential medical peripherals, such as barcode scanners and printers, critical for efficient patient monitoring and documentation. Equipped with versatile I/O options, including USB 3.0, USB-C with display and charging support, and a 3.5 mm audio jack, the MD-130 integrates easily with other medical devices to streamline healthcare operations.

Extended Battery Life for Long Shifts

Powered by a 66.3Wh high-capacity battery, the MD-130 provides up to six hours of continuous use, supporting healthcare professionals through long shifts. The fanless design improves power efficiency, enabling extended operation while maintaining reliable performance for patient care activities.

Advanced Security for Sensitive Healthcare Data

Security is essential in healthcare, and the MD-130 delivers with built-in Windows Hello camera for facial recognition, ensuring access only for authorized users. This biometric security feature safeguards sensitive patient data in compliance with healthcare industry standards. The device also features a rear-facing 5 MP camera with autofocus for high-quality documentation, adding extra versatility for healthcare professionals.

Customizable Options for Expanded Functionality

With optional SSD expansion up to 1 TB and a range of customizable I/O configurations, the MD-130 can be tailored to meet specific medical requirements. A VESA mount offers secure cart attachment, enabling the device to serve as a versatile, multi-functional workstation adaptable to evolving healthcare needs. The MD-130 Medical Tablet PC is purpose-built for healthcare environments, empowering professionals with the tools needed for efficient, reliable patient care.

SPECIFICATIONS

RUGGEDNESS

IP Rating
IP54 Water & Dust Protection

SYSTEM

Processor
Intel Tiger Lake i5-1135G7, Max Turbo Frequency 4.2GHz
8 MB Intel® Smart Cache
GPU
Intel® Iris® Xe Graphics
Memory
16GB LPDDR4X
Storage
NVMe Gen 4 256GB SSD
OS
Windows 11 LTSC
Windows 11 Pro

DISPLAY

Screen Size
13.3” IPS LCD
Resolution
1920 x 1080
Brightness
400 nits Backlight
Touchscreen
Capacitive 10-Point Multi-Touch

COMMUNICATIONS

Ethernet
1 x RJ45 10/100/1000M Port
Wi-Fi
Intel® Wi-Fi 6E AX210 (Support 2.4G & 5G)
Bluetooth
Bluetooth 5.2

POWER

AC Adapter
110-240V AC Input, 19V 3.15A DC Output, Standard US Plug Medical AC Adapter
Battery
11.4V, 5820mAh, 66.3Wh

I/O INTERFACE

Audio
2 x Speaker, 8Ω/2W
2 x Microphone
Camera
Front Camera: 5MP for Windows Hello
Rear Camera: 5MP with Auto Focus
Ports
1 x 3.5mm Audio Jack
1 x 5mm DC Jack
3 x USB 3.0 Type A Ports
1 x USB C Port (Support USB 3.1, Display, and Charging)
Buttons
Power On/Off Button
4 x Programmable Buttons

MECHANICAL

Chassis
Front: Plastic + TPU, Rear: Aluminum Alloy CNC
Dimensions
339 x 235 x 37.5mm
Weight
About 2.4kg
Kickstand
180-degree Rotatable Kickstand
Cooling
Fanless

ENVIRONMENTAL

Operating Temperature
0°C to 40°C
Storage Temperature
-20°C to 60°C
Humidity
10% to 90% Non-condensing

REGULATORY

Certification
FCC, RoHS Compliant, IEC60601-1, IEC60601-1-2
CONFIGURATION
icon BASE CONFIGURATION:
$2,399.00
per unit
in stock
cart ADD TO CART
Quantity:
Get Personalized Offer
Open this products and find more reference
MODEL
MD-130
MD-130
details
hide
products
MD-130
View details
